Wine box bagging machine
Application Scenarios
Product Paramenters
|
WINE BOX BAGGING MACHINE
|
|
| Type |
YH-ZA13A-1
|
|
Machine name
|
WINE BOX BAGGING MACHINE
|
|
power
|
220V、1.5Kw
|
| Speed | 1200-1800pcs/h |
| Applicable product size |
L100-450mm W100-350mm H20-170mm
(Recommended for single specifications)
|
|
Air pressure
|
0.5-0.7mpa
|
|
machine weight
|
450KG
|
|
machine size
|
L*W*H：1485*1430*1620mm
|
Function introduction
Basic function
◆ The equipment mechanism is composed of an automatic rolling film feeding mechanism, automatic pushing material into film mechanism,automatic bag , making mechanism,product converying mechanism,main support mechanism and control mechanism;
◆ The design of each part of the equipment is designed according to the efficiency requirement of 20-30PCS/min;
◆ The equipment is scientifically and simply structured, with high reliability, convenient and quick adjustment and maintenance, and is easy to learn.
