High speed prefabricated bag bagging machine
Application Scenarios
Bath Towel,Towel,Tray-Packed Products,Bread,Snack Bag,Tea Brick,Block Fish Bait,Foundation Box,Sanitary Pad
Product Paramenters
|
High speed prefabricated bag bagging machine |
|
| Type | YH-MA61J |
|
Machine name
|
High speed prefabricated bag bagging machine |
|
power
|
220V、8Kw
|
| Speed | 1200-3000pcs/h |
| Applicable product size | L250-350*W110-220*H40-90mm(other sizes customized) |
|
Air pressure
|
0.5-0.7mpa
|
|
machine weight
|
740KG
|
|
machine size
|
L*W*H：3075*2320*1465mm
|
Function introduction
Basic function
◆ The equipment structure consists of a bag magazine mechanism, automatic bag taking and opening mechanism, automatic bag holding and rotating mechanism, automatic product conveying mechanism, automatic push and bagging mechanism, automatic bag straightening mechanism, automatic bag mouth clamping and translating mechanism, automatic sealing mechanism, product conveying and discharging mechanism, main support structure, and control system;
◆ Each component of the equipment is designed to meet the efficiency requirement of 20-50PCS/S;
◆ The equipment is scientifically and simply structured, with a high degree of automation, strong professionalism, high production efficiency, and low fault rate;
◆ It uses a servo control system, and the touch screen human-machine interface display is clearer, making maintenance more convenient.
